Axial fans for ventilation of tunnels, metro stations and work in the ventilation systems of industrial enterprises. They are designed for a long period of operation at a temperature of transported air from -30° to +45° С or for use for moving a gas-vapor medium with a temperature up to +200° С for 60 minutes.
Nominal diameter
impeller, mm 		N en, KW n en,
rpm 		Airflow
m3/h 		Pressure
Pa 		ID Price,
UAH
ηmax in working zone ηmax in working zone

VOM №8
800 7.5 1500 5700 3000-7000 500 200-600 id40082 Negotiated price

VOM №12
1200 30 1000 15000 8000-20000 650 250-800 id40083 Negotiated price

VOM №14
1400 37 1000 25000 10000-35000 500 200-700 id40084 Negotiated price

VOM №16
1600 75 750 38000 20000-55000 500 200-800 id40086 Negotiated price
1600 45 1000 30000 9000-46000 480 150-600 id40085 Negotiated price

VOM №18
1800 75 750 55000 20000-75000 600 200-800 id40088 Negotiated price
1800 55 1000 45000 20000-65000 600 250-1200 id40087 Negotiated price

VOM №20
2000 75 600 60000 20000-70000 500 150-800 id40089 Negotiated price

VOM №24
2000 110 500 80000 25000-105000 650 300-850 id40090 Negotiated price
VOM axial fans

Fans are manufactured in accordancewith TU U 28.2-24881057-003:2023:

  • with the rotation of the impeller blades not on the move.

Axial fans VOM are intended for ventilation of tunnels and metro stations, and also for work in ventilation systems of other industries.

Fans are designed for a long period of operation at an intermittent air temperature of -30 ° to + 45 ° C and relative humidity up to 98%. Also, the fans are designed for use to move a gas-vapor medium with a temperature of up to + 200 ° C for 60 minutes.

VOM fans are installed

stationary in the ventilation shaft and can drive both separate units and in installations of two fans.

Fans are manufactured:

  • with the possibility of reversal air flow is not less than 70%;
  • with the possibility of reversal air flow is not less than 100%;
