VC 6-28 (VR 120-28) №5 with electric motor AIR 112 М2 7,5 kW 3000 rpm
VC 6-28 (VR 120-28) №5 with electric motor AIR 112 М2 7,5 kW 3000 rpm
VC 6-28 (VR 120-28) №5 with electric motor AIR 112 М2 7,5 kW 3000 rpm
VC 6-28 (VR 120-28) №5 with electric motor AIR 112 М2 7,5 kW 3000 rpm

VC 6-28 (VR 120-28) №5 with electric motor AIR 112 М2 7,5 kW 3000 rpm

ID 9117  In stock
Choose another ›
Choose another ›
Choose another ›
Choose another ›
ID 9117  In stock

Prices for fans with impeller D = 1,05 Dn, D = 1,1 Dn, are specified by manager

Fan's operating point: Airflow m³/h 510-4990, 580-5480, 590-4300, 560-3580
D/Dn 0.9, 0.95, 1, 1.05
Rotation speed, rpm 3000
Material Carbon steel
Rotations of impeller, rpm 2870, 2885, 2886
Pressure ηmax 3440, 3984, 4557, 4959
Fan's operating point: Pressure, Pa 3516-1272, 3903-1559, 4208-4380, 4873-4830
The mass of the fan with el. engine, kg 129,0, 130,0
Pollution limits, mg/m³ 100
Model ВЦ 6-28 (ВР 120-28) №5
Max. transported air temperature, °C
Engine KW / RPM 7.5/3000
Ventilator angle of rotation L 0, L 135, L 180, L 270, L 315, L 45, L 90, R 0, R 135, R 180, R 270, R 315, R 45, R 90
Performance ηmax 2450, 2540, 2210, 3280
Design Schema №1

Dimensions

Overall dimensions of the industrial fan VC 6-28 (VR 120-28) №5

Reviews

There are no reviews yet.

Be the first to review “VC 6-28 (VR 120-28) №5 with electric motor AIR 112 М2 7,5 kW 3000 rpm”

Your email address will not be published. Required fields are marked *

Aerodynamic characteristics

VC 6-28 fan aerodynamic characteristics
at barometric pressure of 760 mm Hg. Art. and temperature 20 ° С

Aerodynamic characteristics VC 6-28 (VR 120-28) №5

Q - air productivity, thousand m3/h
Pv - total pressure
η - coeficient of eficiency
n - quantity of rotations on the impeller, rpm
N - power consumption of the engine, kW
U – wheel peripheral speed, m / s
