VС 14-46 №5 with electric engine AIR 112 MB8 3 kW 750 RPM

Medium-pressure centrifugal fan

ID 8570  In stock
Choose another ›
Choose another ›
Choose another ›
Choose another ›

Medium-pressure centrifugal fan

ID 8570  In stock
Fan's operating point: Airflow m³/h 2800-9810
Pressure ηmax 507
Performance ηmax 5990
Rotations of impeller, rpm 710
Rotation speed, rpm 750
Fan's operating point: Pressure, Pa 407-534
The mass of the fan with el. engine, kg 116
Material Carbon steel
Design Schema №1
Ventilator angle of rotation L 0, L 135, L 180, L 270, L 315, L 45, L 90, R 0, R 135, R 180, R 270, R 315, R 45, R 90
Engine KW / RPM 3/750
Pollution limits, mg/m³ 100
Model ВЦ 14-46 №5
D/Dn 0.95

Dimensions

Габаритные размеры ВЦ 14-46 №5 с эл.двигателем АИР 112 MB8 3 кВт 750 об./мин

Reviews

There are no reviews yet.

Be the first to review “VС 14-46 №5 with electric engine AIR 112 MB8 3 kW 750 RPM”

Your email address will not be published. Required fields are marked *

Aerodynamic characteristics

VC 14-46 fan aerodynamic characteristics
at barometric pressure of 760 mm Hg. Art. and temperature 20 ° С

Aerodynamic characteristics VC 14-46 №5
