VС 4-75 №10 with electric engine AIR 112 MB6 4 kW 1000 RPM

Low pressure centrifugal fan

ID 8712  In stock
Choose another ›
Choose another ›
Choose another ›
Choose another ›

Low pressure centrifugal fan

ID 8712  In stock
Design Schema №5.1, Schema №5.2
D/Dn 1
Rotation speed, rpm 1000
Rotations of impeller, rpm 610
Performance ηmax 20000
Fan's operating point: Airflow m³/h 10640-25800
Pressure ηmax 494
Fan's operating point: Pressure, Pa 588-261
The mass of the fan with el. engine, kg 629
Pollution limits, mg/m³ 100
Model ВЦ 4-75 №10
Max. transported air temperature, °C 80
Engine KW / RPM 4/1000
Ventilator angle of rotation L 0, L 135, L 180, L 270, L 315, L 45, L 90, R 0, R 135, R 180, R 270, R 315, R 45, R 90
Material Carbon steel

Dimensions

Габаритные размеры промышленного вентилятора

Reviews

There are no reviews yet.

Be the first to review “VС 4-75 №10 with electric engine AIR 112 MB6 4 kW 1000 RPM”

Your email address will not be published. Required fields are marked *

Aerodynamic characteristics

VC 4-75 fan aerodynamic characteristics
at barometric pressure of 760 mm Hg. Art. and temperature 20 ° С

Aerodynamic characteristics VC 4-75 №10
