| Material | Carbon steel |
|---|---|
| Fan's operating point: Pressure, Pa | 263-132 |
| Fan's operating point: Airflow m³/h | 2260-4050 |
| Pollution limits, mg/m³ | 100 |
| The mass of the fan with el. engine, kg | 83,4 |
| Model | ВКР №5 |
| Engine KW / RPM | 0.55/1000 |
| Rotations of impeller, rpm | 940 |
VKR №5 with electric motor AIR 71 B6 0,55 kW 1000 rpm
Dimensions
| Модель | Габаритные размеры, мм | ||||||
| D | D1 | D2 | D3 | H | n | d | |
| ВКР №5 с эл.двигателем АИР 71 B6 0,55 кВт 1000 об./мин | 772 | 860 | 795 | 535 | 735 | 8 | 14 |
Aerodynamic characteristics
VKR № 5 fans aerodynamic characteristics
at barometric pressure of 760 mm Hg. Art. and temperature 20 ° С
Q - air productivity, thousand m3/h
Pv - total pressure
η - coeficient of eficiency
n - quantity of rotations on the impeller, rpm
N - power consumption of the engine, kW
- n=1000 rpm - 0,55 kW
- n=1500 rpm - 1,5 kW, 2,2 kW
