VC 6-28 (VR 120-28) №9 with electric motor AIR 250 S2 75 kW 3000 rpm
VC 6-28 (VR 120-28) №9 with electric motor AIR 250 S2 75 kW 3000 rpm
VC 6-28 (VR 120-28) №9 with electric motor AIR 250 S2 75 kW 3000 rpm
VC 6-28 (VR 120-28) №9 with electric motor AIR 250 S2 75 kW 3000 rpm

VC 6-28 (VR 120-28) №9 with electric motor AIR 250 S2 75 kW 3000 rpm

ID 37511  In stock
Choose another ›
Choose another ›
Choose another ›
Choose another ›
ID 37511  In stock
Engine KW / RPM 75.0/3000
Ventilator angle of rotation L 0, L 135, L 180, L 270, L 315, L 45, L 90, R 0, R 135, R 180, R 270, R 315, R 45, R 90
Material Carbon steel
Model VC 6-28 (VR 120-28) №9
Max. transported air temperature, °C
Design Schema №5.1, Schema №5.2
D/Dn 1
Pollution limits, mg/m³ 100
The mass of the fan with el. engine, kg 1014,0, 1021,0
Fan's operating point: Pressure, Pa 7981-4000, 9525-9100
Pressure ηmax 8695, 10405
Performance ηmax 9840, 10740
Rotations of impeller, rpm 2200, 2400
Rotation speed, rpm 3000
Fan's operating point: Airflow m³/h 2640-25000, 2880-18750

Reviews

There are no reviews yet.

Be the first to review “VC 6-28 (VR 120-28) №9 with electric motor AIR 250 S2 75 kW 3000 rpm”

Your email address will not be published. Required fields are marked *

Aerodynamic characteristics

VC 6-28 fan aerodynamic characteristics
at barometric pressure of 760 mm Hg. Art. and temperature 20 ° С

Aerodynamic characteristics VC 6-28 (VR 120-28) №9

Q - air productivity, thousand m3/h
Pv - total pressure
η - coeficient of eficiency
n - quantity of rotations on the impeller, rpm
N - power consumption of the engine, kW
U – wheel peripheral speed, m / s
