| Fan's operating point: Pressure, Pa | 3030-1730 |
|---|---|
| Material | Carbon steel |
| Ventilator angle of rotation | L 0, L 135, L 180, L 270, L 315, L 45, L 90, R 0, R 135, R 180, R 270, R 315, R 45, R 90 |
| D/Dn | 1 |
| Fan's operating point: Airflow m³/h | 55290-220510 |
| Pollution limits, mg/m³ | 100 |
| Engine KW / RPM | 200/600 |
| Design | Schema №1, Schema №3 |
| Motor type | ДАЗО |
| Model | ДН №24 |
ДН №24 с эл.двигателем ДАЗО4-450X-10МТ2 200 кВт 600 об./мин
Leave a request
Leave your phone number and email. Our manager will confirm the configuration, price and lead time.
Frequently asked questions
How can I get a price for a fan?
Price depends on the configuration and order volume and is not published on the site. Leave a request on this page or call us — a manager will calculate the cost.
What is the manufacturing lead time?
Lead time depends on the model and configuration and is confirmed individually for each order.
Do you manufacture non-standard equipment to order?
Yes, in addition to standard models we manufacture non-standard ventilation equipment to the customer's specific requirements.
Do you export equipment abroad?
Yes, we supply equipment to customers across Europe, Asia, North America and Africa.
How do I submit a request?
Fill in the form on this page (phone and email are required) or call us — a manager will contact you during business hours.
ДН №24 с эл.двигателем ДАЗО4-450X-10МТ2 200 кВт 600 об./мин
DN smoke exhauster is designed for exhausting flue gases from the furnaces of boiler units equipped with ash collecting systems or working on gas-oil mixtures. Designed for long-term indoor and outdoor work in a temperate climate. The maximum temperature of the flue gas at the inlet should not exceed + 200-250 ° C. And in the scroll housing do not fall below -30 ° C. Dustiness of flue gases is not higher than 2 g/m3.Dimensions
