| Fan's operating point: Airflow m³/h | 3880-13610, 4510-16700 |
|---|---|
| Pressure ηmax | 950, 1068 |
| Performance ηmax | 8300, 9640 |
| Rotations of impeller, rpm | 960 |
| Rotation speed, rpm | 1000 |
| Fan's operating point: Pressure, Pa | 762-1001, 816-1190 |
| The mass of the fan with el. engine, kg | 158.5, 160.1 |
| Material | Carbon steel |
| Design | Schema №1 |
| Ventilator angle of rotation | L 0, L 135, L 180, L 270, L 315, L 45, L 90, R 0, R 135, R 180, R 270, R 315, R 45, R 90 |
| Engine KW / RPM | 7.5/1000 |
| Pollution limits, mg/m³ | 100 |
| Model | ВЦ 14-46 №5 |
| D/Dn | 0.95, 1 |
VС 14-46 №5 with electric engine AIR 132 M6 7,5 kW 1000 RPM
Dimensions
Aerodynamic characteristics
VC 14-46 fan aerodynamic characteristics
at barometric pressure of 760 mm Hg. Art. and temperature 20 ° С
